EC200UCNAA-N05-SGNSA Mobile Modules External Antenna

Send Inquiry

Request To Call Back

EC200UCNAA-N05-SGNSA Mobile Modules External Antenna

Name: EC200UCNAA-N05-SGNSA Mobile Modules External Antenna
Brand: RKSEMITRONICS
Price: 780 INR
Availability: InStock

Price 780 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

EC200UCNAA-N05-SGNSA Mobile Modules External Antenna Specification

Power Supply
External

Operating Temperature
-40C to +85C

Features
Low Power Consumption, Global Band Support, Extended Temperature Range, Plug-and-Play with External Antenna

Power Source
External DC Supply

Components
Module, External Antenna Connector

Display Type
No Display

Output
Antenna Signal, UART/USB Data

Usage
Wireless Data Transmission

IP Rating
Not Rated

Interface
UART, USB 2.0, SIM, Antenna, GPIO

Input
SIM Card, Power Supply

Response Time
Instant Data Transfer

Product Type
Mobile LTE Communication Module

Application
IoT Devices, Industrial Automation, Telematics, Smart Metering

Rated Voltage
3.3V DC

Supply Voltage
3.3V to 4.3V (typical 3.8V)

Size
30.0mm x 30.0mm

Dimension (L*W*H)
30 x 30 x 2.5 mm

Function
Cellular Communication Module

Color
Black

Weight
18g (typical)

Current Rating
Max 2A (peak)

Capacity
Supports LTE Cat 1, Up to 10 Mbps downlink

Thickness
Approx. 2.5mm

Frequency
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28. LTE-TDD: B38/B39/B40/B41. WCDMA: B1/B2/B4/B5/B6/B8/B19. GSM: B2/B3/B5/B8

SIM Interface
1.8V/3.0V

Storage Temperature
-45C to +90C

GNSS Support
Optional (GPS/GLONASS/BeiDou)

Network Technology
LTE Cat 1, GSM, WCDMA

Firmware Upgrade
Supports DFOTA (Device Firmware Upgrade Over The Air)

RoHS Compliance
Yes

Data Rate
LTE Uplink up to 5 Mbps, Downlink up to 10 Mbps

Voice Capability
VoLTE and CSFB

Security
Embedded TLS/SSL, Secure Boot

Mounting Type
SMD/Surface Mount

SMS/MMS
Supported

Antenna Interface
External SMA Female

EC200UCNAA-N05-SGNSA Mobile Modules External Antenna Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About EC200UCNAA-N05-SGNSA Mobile Modules External Antenna

Manufacturer: Quectel Product Category: Mobile Modules RoHS: Details Packaging: Reel Brand: Quectel Moisture Sensitive: Yes Product Type: Cellular Modules Subcategory: Wireless & RF Modules

Robust Connectivity and Performance

Engineered for seamless wireless data transmission, the EC200UCNAA-N05-SGNSA supports multiple network technologies, including LTE Cat 1, GSM, and WCDMA. Its versatile frequency band compatibility ensures global connectivity for a wide range of IoT and industrial applications. The module supports instant data transfer, making it ideal for mission-critical uses.

Flexible Integration and Security

With a compact 30mm x 30mm footprint and surface-mount design, this module is easy to incorporate into various devices. It features secure boot, embedded TLS/SSL, and an external SMA antenna connector for flexible installation and optimum signal reception. DFOTA support allows remote firmware upgrades, simplifying maintenance.

Designed for Demanding Environments

Extended operating (-40C to +85C) and storage (-45C to +90C) temperature ranges enable reliable operation in harsh industrial settings. The low power consumption and wide supply voltage range (3.3V to 4.3V) make it suitable for energy-sensitive applications, while its sturdy build ensures durability across diverse applications.

FAQ's of EC200UCNAA-N05-SGNSA Mobile Modules External Antenna:

Q: How do I connect an external antenna to the EC200UCNAA-N05-SGNSA module?

A: The module provides an external SMA female connector, enabling easy attachment of various compatible antennas. Simply connect your antenna's SMA male plug to the module's SMA female port to optimize signal strength for your application.

Q: What network technologies are supported by this module?

A: This module supports LTE Cat 1, GSM, and WCDMA networks, covering a wide range of frequency bands for global operation. It also offers optional GNSS support for GPS, GLONASS, or BeiDou as required.

Q: When should I use DFOTA (Device Firmware Upgrade Over The Air) with this module?

A: DFOTA should be used whenever a firmware update is required to fix bugs, improve performance, or add features. It enables remote and secure updates, reducing device downtime and physical maintenance needs.

Q: Where can the EC200UCNAA-N05-SGNSA be deployed?

A: Designed for versatility, it is suitable for IoT devices, industrial automation, telematics, and smart metering projects, especially where reliable cellular connectivity and extended temperature tolerance are necessary.

Q: What is the typical process for integrating the module into my device?

A: Integration involves surface-mounting the module (SMD), connecting the external antenna, interfacing with the SIM (1.8V/3.0V), and supplying appropriate power (3.3V - 4.3V). Data communication is enabled via UART or USB interfaces.

Q: How is data protected on the EC200UCNAA-N05-SGNSA?

A: The module incorporates embedded TLS/SSL protocols and secure boot features to ensure encrypted communication and protect against unauthorized access or software tampering.

Q: What are the key benefits of using this module for wireless data transmission?

A: It provides plug-and-play integration, global band support, secure data transfer, low power consumption, and stable operation across wide temperature ranges-making it ideal for both small-scale and industrial applications.
