MCIMX6X4CVM08AC Integrated circuit

Name: MCIMX6X4CVM08AC Integrated circuit
Brand: RKSEMITRONICS
Price: 1400 INR
Availability: InStock

Price 1400 INR/ Piece

Get a Price/Quote

MOQ : 5 Pieces

MCIMX6X4CVM08AC Integrated circuit Specification

Interface
I2C, SPI, UART, USB, CAN, Ethernet, SATA, PCIe, SDIO

Components
i.MX 6SoloX/6DualLite/6QuadPlus ARM Cortex-A9 Processor

Features
ARM Cortex-A9 core, advanced multimedia processing, hardware security, multi-interface support

Usage
Embedded applications, industrial automation, automotive

Power Source
External regulated supply

Sensors Specification
Supports interfacing with various external sensors via I2C, SPI

Power Supply
External, Multi-Rail

Response Time
N/A (processor) - depends on end application

Processor Speed
800 MHz

Thermal Conductivity
Dependent on package, typically 6-10 W/mK for exposed pad

Operating Temperature
-40C to +105C (industrial grade)

Display Type
Supports LVDS, RGB, MIPI-DSI interfaces

Input
Digital Signal Inputs

Resolution
Supports up to 1920 x 1080 pixels (Full HD)

Output
Digital Signal Outputs

IP Rating
N/A (component level)

Product Type
Microprocessor Unit (MPU)

Application
Industrial control, consumer electronics, automotive devices, HMI

Rated Voltage
3.3V, 1.5V, 1.8V (multiple supply rails)

Supply Voltage
Min 1.1V, Max 3.3V (core and I/O)

Size
17 mm x 17 mm (

Dimension (L*W*H)
17 mm x 17 mm x 1.45 mm

Function
Integrated Circuit/Processor

Color
Black

Weight
Approximately 5g (package-dependent)

Thickness
1.45 mm (typical package thickness)

Current Rating
Max 1.5A (dependent on application and peripherals)

Capacity
Up to 1GB embedded memory supported (external DDR3/DDR3L/LPDDR2)

Frequency
800 MHz (processor clock)

Number of Cores
Single/Dual ARM Cortex-A9 + ARM Cortex-M4 core (heterogeneous)

Marking Code
MCIMX6X4CVM08AC

On-Chip Memory
256KB L2 cache, 64KB RAM (M4)

RoHS Status
Compliant

Graphics
Vivante GC880 GPU (2D/3D acceleration)

Package Type
BGA (Ball Grid Array), 0.8 mm pitch, 624 balls

ESD Protection
Standard JEDEC IC ESD protection

Video
Supports 1080p video encode/decode

Lifecycle Status
Active production

On-chip Peripherals
GPU, VPU, Image Processing Unit, Security Engine

External Memory Interface
Supports DDR3, DDR3L, LPDDR2, NAND, NOR, eMMC

MCIMX6X4CVM08AC Integrated circuit Trade Information

Minimum Order Quantity
5 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About MCIMX6X4CVM08AC Integrated circuit

Manufacturer: NXP Product Category: Processors - Application Specialised RoHS: Details Mounting Style: SMD/SMT Package/Case: MAPBGA-529 Series: i.MX6SX Application: Industrial Core: ARM Cortex A9, ARM Cortex M4 Number of Cores: 2 Core Data Bus Width: 32 bit Maximum Clock Frequency: 227 MHz, 800 MHz L1 Cache Instruction Memory: 16 kB, 32 kB L1 Cache Data Memory: 16 kB, 32 kB Operating Supply Voltage: 950 mV to 1.5 V Minimum Operating Temperature: - 40 C Maximum Operating Temperature: + 105 C Packaging: Tray Brand: NXP Semiconductors Data RAM Size: 144 kB Data ROM Size: 96 kB I/O Voltage: 1.8 V, 2.5 V, 2.8 V, 3.15 V Instruction Type: Floating Point Interface Type: CAN, ESAI, Ethernet, I2C, SAI, SPI, UART, USB L2 Cache Instruction / Data Memory: 256 kB Memory Type: DDR3, DDR3L, LPDDR2 Moisture Sensitive: Yes Processor Series: i.MX 6SoloX Product Type: Processors - Application Specialized 420 Subcategory: Processors - Application Specialized Tradename: i.MX Watchdog Timers: Watchdog Timer Part # Aliases: Unit Weight: 1 g

High Performance for Embedded Applications

With its combination of ARM Cortex-A9 and Cortex-M4 cores, the MCIMX6X4CVM08AC provides impressive processing power for demanding embedded, industrial automation, and automotive applications. Whether you require advanced multimedia, real-time control, or secure data processing, its hardware capabilities offer robust support for a range of use cases.

Versatile Multimedia and Connectivity Options

The integrated Vivante GC880 GPU enables 2D/3D graphics acceleration, while the VPU supports 1080p video encoding and decoding. Multiple interfaces like LVDS, MIPI-DSI, and RGB ensure compatibility with various displays. The processor is ideal for HMI and infotainment systems, supporting extensive sensor, communication, and storage interfaces.

Secure, Reliable, and Industrial-Grade Design

This IC is compliant with RoHS requirements, meets JEDEC ESD protections, and is qualified for operation from -40C to +105C. Built-in security engines protect sensitive data, making it suitable for mission-critical applications in harsh industrial and automotive environments.

FAQ's of MCIMX6X4CVM08AC Integrated circuit:

Q: How can the MCIMX6X4CVM08AC be integrated into industrial and automotive systems?

A: You can integrate the MCIMX6X4CVM08AC into embedded systems by leveraging its multiple interfaces such as I2C, SPI, CAN, Ethernet, and PCIe for sensor and device communications. Its industrial temperature range and robust package make it ideal for harsh environments found in manufacturing automation and automotive in-vehicle systems.

Q: What benefits does the heterogeneous dual-core architecture offer?

A: With both ARM Cortex-A9 and Cortex-M4 cores, the IC enables concurrent high-performance computing and real-time control in a single package. This architecture allows multitasking-such as running a user interface on the A9 while performing real-time sensor data processing on the M4-boosting efficiency and system flexibility.

Q: When should I use the built-in hardware security features?

A: Use the security engine whenever your application requires encrypted communications, secure boot, or data protection. These features are beneficial in systems that handle sensitive industrial, automotive, or consumer data, helping safeguard information from unauthorized access.

Q: Where is external memory, such as DDR3, connected on this processor?

A: External memory modules like DDR3, DDR3L, or LPDDR2 are interfaced directly via the processor's memory controller pins in the BGA package. Supported memory expansion facilitates efficient data handling for complex applications requiring up to 1GB of memory.

Q: What display options are supported and how do they enhance applications?

A: The MCIMX6X4CVM08AC supports LVDS, RGB, and MIPI-DSI display interfaces. This versatility allows manufacturers to connect a wide range of high-resolution screens-up to 1920 x 1080 pixels-greatly enhancing the visual experience in devices such as HMIs, infotainment panels, and consumer electronics.

Q: How does the IC manage heat and ensure reliability in operation?

A: This device features a package with good thermal conductivity (6-10 W/mK, exposed pad), and is designed for industrial temperature operation. Proper PCB layout, heatsinking, and airflow can further improve thermal management to maintain reliability even under demanding workloads.
