5STP1818F0003 Thyristor Module

Name: 5STP1818F0003 Thyristor Module
Brand: RKSEMITRONICS INDIA PRIVATE LIMITED
Price: 14000 INR
Availability: InStock

Price 14000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

5STP1818F0003 Thyristor Module Specification

Input
Gate Trigger Signal

Output
Controlled Voltage/Current

Interface
Stud Terminal, Flexible Cable

IP Rating
IP00 (Open-type Module)

Features
Rugged Construction, High Surge Current Capability

Components
Thyristor, Fused Connection Leads

Power Supply
Electrical

Power Source
External Power Source Required

Usage
High Power Industrial Applications

Thermal Conductivity
High, Suitable for Heat Sink Mounting

Operating Temperature
-40C to 125C

Response Time
Fast Switching

Product Type
Thyristor Module

Application
Electric Device

Rated Voltage
4500 V

Supply Voltage
Up to 4500 V

Size
Standard Power Module Size

Dimension (L*W*H)
Approx. 120 mm (Diameter) x 40 mm (Height)

Function
AC/DC Power Control, Rectification, Switching

Color
Metallic / White

Weight
Approx. 3.5 kg

Current Rating
1818 A (Average On-State Current)

Thickness
Standard (as per ABB design)

Capacity
High Current Capacity

Frequency
Power Frequency / 50-60 Hz

Peak Surge Current (ITSM)
28,000 A

Peak Repetitive Off-State Voltage (VDRM)
4500 V

Compliance
RoHS / CE (Depending on Batch)

Storage Temperature
-40C to 150C

Gate Trigger Current (IGT)
Max. 300 mA

Isolation Voltage
As per manufacturer design

Mounting Type
Stud / Clamp Mounting

Part Number
5STP1818F0003

Housing Material
Ceramic/Metal

5STP1818F0003 Thyristor Module Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About 5STP1818F0003 Thyristor Module

The 5STP1818F0003 Thyristor Module stands as an in-demand champion for high-power industrial applications, offering fresh advancements in AC/DC power control and rectification. Designed for triumphant performance, it features a peak repetitive off-state voltage of 4500V, a robust surge current rating of 28,000A, and a gate trigger current of only 300mA max. Its opulent ceramic/metal housing ensures rugged durability and excellent thermal conductivity. Enjoy instant checkout for this metallic-white module, which is RoHS/CE compliant and engineered for seamless stud or clamp mounting. Elevate your power switching needs with a product built for reliability and speed.

Distinctive Features & Versatile Applications

The 5STP1818F0003 Thyristor Module boasts high surge current capability, fast switching response, and superior thermal conductivity-crafted for opulent performance. Its robust ceramic/metal build guarantees longevity, while the open-type IP00 module is suitable for heat sink mounting. Widely used in electric devices, heavy-duty rectification, and AC/DC power controls, it effortlessly integrates into railways, HVDC transmission, renewables, and industrial drives. Compatible with stud terminals and flexible cables, it supports reliable power control across critical application media.

Global Supply, Domestic Rates & Secure Payment Offers

We supply the 5STP1818F0003 module internationally and throughout India's main industrial markets. The module's competitive rate combines world-class engineering with cost-effective solutions for bulk and spot offers alike. Suppliers and traders ensure rapid dispatch and flexible payment terms, including advance, cheque, and online modes. Known for prompt delivery and responsive support, this module is your perfect partner in both main export markets and key domestic segments, guaranteeing satisfaction every time you order.

FAQ's of 5STP1818F0003 Thyristor Module:

Q: How does the 5STP1818F0003 Thyristor Module operate in high-power industrial applications?

A: The module manages AC/DC power control, switching, and rectification with high current capacity, supporting robust performance in demanding industrial environments such as railways, HVDC transmission, and heavy-duty machinery.

Q: What features make this thyristor module a champion in power electronics?

A: Its high surge current rating, rapid switching capability, robust ceramic/metal housing, and superior thermal management ensure reliable, opulent performance in critical applications, positioning it as a champion in the field.

Q: Where can the 5STP1818F0003 be applied most effectively?

A: This module excels in electric devices, industrial drives, renewable energy systems, and infrastructure requiring precise, reliable power switching and rectification. Its design supports flexible integration in various industrial systems.

Q: When should the module be mounted on a heat sink?

A: Heat sink mounting is recommended whenever the module is used in high-current or continuous operation scenarios, effectively managing thermal dissipation and maintaining safe operating temperatures.

Q: What are the major benefits of using a RoHS/CE-compliant thyristor module?

A: RoHS/CE compliance means the module meets stringent safety and environmental standards, ensuring safe handling, international acceptance, and long-term operational reliability in global industrial settings.

Q: How does the instant checkout process work for this product?

A: Customers can purchase the module via our secure online portal with instant checkout, ensuring rapid order confirmation and streamlined processing for urgent supply needs.
