ATMEGA809-AU Semiconductor IC

Name: ATMEGA809-AU Semiconductor IC
Brand: RKSEMITRONICS INDIA PRIVATE LIMITED
Price: 110 INR
Availability: InStock

Price 110 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ATMEGA809-AU Semiconductor IC Specification

Product Type
Semiconductor IC

Application
Embedded systems, Industrial control, Consumer electronics, Automotive, IoT devices

Supply Voltage
1.8V to 5.5V

Dissipation Power
Typically < 500 mW

Operating Temperature
-40C to 85C

Power Consumption
Low power consumption (Exact value depends on operating conditions)

Temperature Range
-40C to 85C

Input Voltage
1.8V to 5.5V

Voltage Regulator Type
External required (no built-in regulator)

Size
QFP-48 package (Quad Flat Package, 7mm x 7mm approx.)

Weight
Approx. 1g

Clock Speed
Up to 20 MHz

Program Memory Size
8KB Flash

Number of I/O Pins
41

Data Bus Width
8-bit

Package / Case
TQFP-48 (Thin Quad Flat Package)

Oscillator Type
Internal and external

RoHS Compliant
Yes

EEPROM Size
256 Bytes

RAM Size
512 Bytes SRAM

Core Processor
AVR 8-bit

Peripherals
Timers, PWM, USART, SPI, I2C, ADC

Mounting Type
Surface Mount

ATMEGA809-AU Semiconductor IC Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About ATMEGA809-AU Semiconductor IC

Experience an elite blend of performance and versatility with the illustrious ATMEGA809-AU Semiconductor IC. Take advantage of this 8-bit AVR core masterpiece, featuring 8KB Flash, 512 Bytes SRAM, and 256 Bytes EEPROM, all engineered for transcendent efficiency. Operating up to 20 MHz and supporting a multitude of peripherals-timers, PWM, USART, SPI, I2C, ADC-this TQFP-48 package delivers a true bargain for embedded, industrial, and IoT innovators. RoHS compliant and crafted for reliability within -40C to 85C, it stands as a testament to technological excellence.

Versatile Applications and Uses

The ATMEGA809-AU Semiconductor IC is masterfully developed for embedded systems, industrial control, automotive, and consumer electronics. Its prominent utility in IoT devices and plant automation demonstrates expansive capabilities. These core attributes make it an illustrious choice for innovative applications, providing seamless integration in various high-demand environments such as smart meters and automation panels.

Delivery Time, Payment Terms, and Export Markets

Our commitment to prompt transportation ensures swift dispatch, with packing & dispatch tailored to protect each masterpiece IC. Main export markets include Europe, Asia, and beyond, catering to suppliers and traders across the globe. Payment terms are flexible to support diverse procurement needs, and drop-off arrangements are streamlined for hassle-free customer experiences.

FAQ's of ATMEGA809-AU Semiconductor IC:

Q: How can the ATMEGA809-AU be integrated in automotive applications?

A: The ATMEGA809-AU supports reliable embedded control and communication features necessary for automotive systems, such as sensor interfaces and real-time monitoring, making integration seamless for designers.

Q: What are the primary benefits for using the ATMEGA809-AU in IoT devices?

A: This IC's low power consumption and extensive connectivity options (USART, SPI, I2C, ADC) offer paramount benefits for IoT devices, enhancing efficiency and communication flexibility.

Q: Where is the ATMEGA809-AU most commonly used?

A: It is widely used in industrial control panels, embedded systems, automotive modules, and consumer electronics, thriving in both large-scale manufacturing and experimental prototypes.

Q: What is the delivery process for international orders?

A: Products are expertly packed and dispatched via reliable transportation channels, with drop-off and tracking details provided to ensure timely and secure delivery across all export markets.

Q: How does the ATMEGA809-AU ensure low power consumption?

A: This semiconductor IC is architected with advanced design techniques, balancing performance with energy efficiency to minimize power usage, which is especially beneficial for battery-powered and portable devices.
