MAX16126TCA+T IC

Name: MAX16126TCA+T IC
Brand: RKSEMITRONICS INDIA PRIVATE LIMITED
Price: 175 INR
Availability: InStock

Price 175 INR/ Piece

Get a Price/Quote

MOQ : 30 Pieces

MAX16126TCA+T IC Specification

Features
Low Supply Current, Precision Monitoring, Multiple Threshold Options

Input
Logic Level Signals

Output
Open-Drain, Push-Pull

Components
IC Chip

Power Supply
2.7V to 5.5V

Power Source
DC Power Supply

Response Time
Fast Response (25s typ)

Usage
Electronic Circuits, Power Sequencing

Operating Temperature
-40C to +125C

Product Type
Integrated Circuit (IC)

Application
Reset Monitor, Power-On Reset, Microcontroller Monitoring

Rated Voltage
Up to 5.5V (VCC Max)

Supply Voltage
2.7V to 5.5V

Size
SOT-23-8

Dimension (L*W*H)
Approx. 2.9mm x 1.6mm (SOT-23-8)

Function
Voltage Monitor IC

Color
Black (Package)

Current Rating
Minimum Supply Current: 4.5A typ

Thickness
Standard SOT-23-8 Package

Part Number
MAX16126TCA+T

Maximum Operating Voltage
5.5V

Mounting Type
Surface Mount

RoHS Status
RoHS Compliant

Number of Channels
2

Reset Output Types
Push-Pull and Open-Drain

Package / Case
SOT-23-8

Typical Supply Current
4.5A

Minimum Operating Voltage
2.7V

MAX16126TCA+T IC Trade Information

Minimum Order Quantity
30 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About MAX16126TCA+T IC

Manufacturer: Analog Devices Inc. Product Category: Supervisory Circuits RoHS: Details Type: Voltage Supervisory Mounting Style: SMD/SMT Package/Case: TQFN-12 Threshold Voltage: Adjustable Number of Inputs Monitored: 1 Input Output Type: Active Low, Open Drain Manual Reset: No Manual Reset Watchdog Timers: No Watchdog Battery Backup Switching: No Backup Reset Delay Time: 150 ms Supply Voltage - Max: 30 V Minimum Operating Temperature: - 40 C Maximum Operating Temperature: + 125 C Series: MAX16126 Packaging: Reel Packaging: Cut Tape Packaging: MouseReel Brand: Analog Devices / Maxim Integrated Product Type: Supervisory Circuits 2500 Subcategory: PMIC - Power Management ICs Part # Aliases: MAX16126 Unit Weight: 20 mg

Precision Voltage Monitoring

The MAX16126TCA+T offers accurate supervision for vital system voltages with its dual channels and multiple threshold options. Its ability to monitor up to two independent rails makes it an effective solution in ensuring system health and operational stability in microcontroller-based designs.

Versatile Output Configurations

This IC provides both push-pull and open-drain configurable reset outputs, allowing integration flexibility with diverse logic families. These output types cater to a broad range of system requirements for reset or power sequencing, facilitating smooth and predictable system start-up behavior.

Compact and Efficient Design

Housed in a standard SOT-23-8 black package, the MAX16126TCA+T combines a minimal footprint (approx. 2.9mm x 1.6mm) with low supply current, supporting space-constrained environments while maintaining minimal power consumption-critical for portable or high-density electronic systems.

FAQ's of MAX16126TCA+T IC:

Q: How does the MAX16126TCA+T ensure system reliability in electronic circuits?

A: By continuously monitoring supply voltages on two independent channels, the MAX16126TCA+T promptly asserts a reset output when voltages fall outside specified thresholds. This helps prevent malfunction or erratic operation in microcontrollers and digital circuits, enhancing system reliability.

Q: What reset output types are available, and how do they benefit system integration?

A: The device features both push-pull and open-drain reset outputs. Push-pull is suitable for driving logic signals directly, while open-drain allows for wired-AND configurations and interfacing with various voltage levels, increasing design flexibility.

Q: Where is the MAX16126TCA+T typically used?

A: It is commonly utilized in embedded systems, microcontroller monitoring, power-on reset functions, and complex power sequencing in electronic devices where robust voltage supervision is critical.

Q: When should I consider using this voltage monitor IC in my application?

A: Select the MAX16126TCA+T when your design demands precise voltage threshold detection, rapid response to voltage drops or surges, minimal current consumption, and the need for dual-channel supervision, especially in applications with strict power-up sequencing or reliability requirements.

Q: What is the process for mounting the MAX16126TCA+T in a circuit board?

A: This IC is designed for surface mount placement using standard reflow soldering techniques. Its SOT-23-8 package allows for straightforward integration into automated PCB assembly lines, saving both time and manufacturing cost.

Q: How does the RoHS compliance of MAX16126TCA+T benefit my product development?

A: RoHS compliance ensures that the MAX16126TCA+T is free from certain hazardous substances, supporting environmental regulations and enabling global market access without additional certification concerns.
