Operational Amplifiers

• Application
• High-Speed Signal Processing Applications

• Capacity
• Dual Op-Amp

• Color
• Black (Package)

• Components
• Integrated Circuit

• Current Rating
• 8.2mA (per amplifier, typical)

• Dimension (L*W*H)
• 5.0 x 4.0 x 1.5 mm (Approx.)

• Features
• Low Noise, High Slew Rate, Wide Bandwidth, Rail-to-Rail Output

• Frequency
• 180 MHz (Gain Bandwidth Product)

• Function
• High-Speed Operational Amplifier

• Input
• Differential

• Interface
• Standard IC Pinout

• Operating Temperature
• -40C to +125C

• Output
• Dual Channel

• Power Source
• External Supply

• Power Supply
• Dual or Single Supply

• Product Type
• Operational Amplifier IC

• Rated Voltage
• 36V (Maximum Supply Voltage)

• Response Time
• Fast Slew Rate

• Size
• SOIC-8 (Surface Mount)

• Supply Voltage
• 4.5V to 36V

• Thermal Conductivity
• Standard IC package

• Thickness
• Standard SOIC-8 Package

• Usage
• Signal Amplification, Data Acquisition, Audio, Test Equipment

• Weight
• Approx. 0.5g

• Application
• Instrumentation, Data Acquisition, Portable Devices, Signal Conditioning

• Capacity
• 2 Independent Channels

• Color
• Black (IC Body)

• Components
• Integrated Circuits

• Current Rating
• 700 A per Amplifier (Typ)

• Dimension (L*W*H)
• 4.90 mm x 3.91 mm x 1.75 mm (SOIC-8 Package)

• Features
• Low Offset Voltage, Rail-to-Rail Input/Output, Low Power

• Frequency
• 1 MHz (Gain Bandwidth Product)

• Function
• General Purpose Operational Amplifier

• IP Rating
• Not Rated

• Input
• Differential, Rail-to-Rail

• Interface
• Analog IC

• Operating Temperature
• -40C to +125C

• Output
• Rail-to-Rail

• Power Source
• External DC Supply

• Power Supply
• Single or Dual Supply

• Product Type
• Dual Operational Amplifier IC

• Rated Voltage
• 5.5V (Maximum)

• Resolution
• Analog, Not Applicable

• Response Time
• Slew Rate 0.7 V/s (typical)

• Size
• 8-SOIC (Small Outline Integrated Circuit)

• Supply Voltage
• 2.7V to 5.5V

• Thermal Conductivity
• Low, Standard for Small ICs

• Thickness
• Max 1.75 mm (body)

• Usage
• Signal Amplification, Active Filtering, Analog Circuits

• Weight
• Approx. 100 mg
