TMS320F28027FPTT 32-bit Microcontrollers

Name: TMS320F28027FPTT 32-bit Microcontrollers
Brand: RKSEMITRONICS
Price: 485 INR
Availability: InStock

Price 485 INR/ Piece

Get a Price/Quote

MOQ : 20 Pieces

TMS320F28027FPTT 32-bit Microcontrollers Specification

Resolution
12-bit (ADC Resolution)

Output
PWM, Digital and Analog Outputs

Display Type
No Display

Power Supply
3.3 V DC

Processor Speed
60 MHz

Input
Digital and Analog (ADC) Inputs

Power Source
External DC Supply

Interface
I2C, SPI, UART, GPIO, PWM

Components
Microcontroller IC

Features
Flash memory, Low power, High-speed PWM, On-chip oscillator, Brown-out reset

Response Time
Low-latency, Typical for DSP Controllers

Sensors Specification
Integrated ADC (12-bit, up to 13 channels)

Usage
Industrial Automation, Motor Control, Embedded Systems

Operating Temperature
-40C to 105C

Product Type
32-bit Microcontroller

Application
Motor Control, Power Conversion, General Purpose Embedded Applications

Rated Voltage
3.3 V

Supply Voltage
2.97 V to 3.63 V

Size
32-pin LQFP (7x7 mm)

Dimension (L*W*H)
7 mm x 7 mm x 0.85 mm

Function
Digital Signal Processing, Real-Time Control

Color
Black (package)

Weight
Approximately 0.1 g

Capacity
FLASH 64 KB, SRAM 8 KB

Current Rating
Max 20 mA (per I/O)

Thickness
0.85 mm (typical, package)

Frequency
60 MHz (Max CPU Clock)

SRAM
8 KB

JTAG Debug Interface
Yes

Core Architecture
C28x

Watchdog Timer
Yes

Flash Memory
64 KB

Operating Modes
Sleep, Halt, Standby, Active

PWM Outputs
Up to 8 channels

ADC
12-bit, up to 13 channels, 4.6 MSPS

DMA Channels
Up to 6

Package
LQFP-32

Peripheral Connectivity
I2C, SPI, UART/SCI, GPIO

ESD Protection
Class 2 (HBM)

On-chip Oscillator
Yes

Timers
3 x 32-bit CPU timers

Lead-Free Status
Lead-Free

RoHS Compliant
Yes

TMS320F28027FPTT 32-bit Microcontrollers Trade Information

Minimum Order Quantity
20 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About TMS320F28027FPTT 32-bit Microcontrollers

Manufacturer: Texas Instruments Product Category: 32-bit Microcontrollers - MCU RoHS: Details Series: TMS320F28027F Mounting Style: SMD/SMT Package/Case: LQFP-48 Core: C28x Program Memory Size: 64 kB Data RAM Size: 12 kB Data Bus Width: 32 bit ADC Resolution: 12 bit Maximum Clock Frequency: 60 MHz Number of I/Os: 22 I/O Supply Voltage - Min: 1.71 V Supply Voltage - Max: 1.89 V Minimum Operating Temperature: - 40 C Maximum Operating Temperature: + 125 C Packaging: Tray Brand: Texas Instruments Data RAM Type: SARAM Interface Type: I2C, SPI, UART Moisture Sensitive: Yes Number of ADC Channels: 13 Channel Number of Timers/Counters: 3 Timer Operating Supply Voltage: 1.8 V Product: MCU Product Type: 32-bit Microcontrollers - MCU Program Memory Type: Flash

High-Performance DSP Computing

Powered by the C28x architecture and operating at a maximum clock frequency of 60 MHz, the TMS320F28027FPTT microcontroller delivers fast and precise digital signal processing. Its on-chip flash and SRAM memory facilitate real-time control algorithms, making it ideal for complex applications that demand high-speed computation and rapid response times.

Versatile Connectivity and Control

Supporting standard interfaces such as I2C, SPI, UART/SCI, and multiple GPIOs, this device enables seamless integration with peripherals. With up to 8 PWM outputs and 3 CPU timers, it meets the requirements for precise motor control and power conversion systems, while flexible input and output options suit a broad array of embedded solutions.

Robust Design for Industrial Use

Built to withstand industrial conditions, the TMS320F28027FPTT operates reliably in temperatures ranging from -40C to 105C. It features Class 2 ESD protection, a lead-free and RoHS-compliant package, and an on-chip brown-out reset for enhanced safety. Its energy-efficient modes help optimize power consumption across various operational states.

FAQ's of TMS320F28027FPTT 32-bit Microcontrollers:

Q: How can the TMS320F28027FPTT microcontroller be used in motor control applications?

A: The TMS320F28027FPTT features high-speed PWM outputs, up to 8 channels, and a 12-bit ADC with up to 13 channels, enabling precise motor speed and position sensing. Its real-time DSP processing powers fast control loop execution, making it well-suited for use in modern motor control systems.

Q: What are the main benefits of using this microcontroller for industrial automation projects?

A: Its robust ESD protection, wide operating temperature range, multiple power-saving modes, and versatile peripheral interfaces ensure reliable operation in industrial environments. The device's fast processing capabilities also allow for efficient real-time control and rapid system response.

Q: When should I utilize the low-power modes available on the TMS320F28027FPTT?

A: Low-power modes like Sleep, Halt, and Standby are best used when the application requires minimal energy consumption, such as during idle system states or when waiting for an external event. These modes help reduce overall power usage while retaining quick wake-up capabilities.

Q: Where can I integrate this microcontroller within embedded designs?

A: The TMS320F28027FPTT can be used in a variety of embedded applications, including motor control drives, power conversion units, sensor interfacing systems, and general-purpose automation controllers, thanks to its flexible I/O and high-performance core.

Q: What process is recommended for programming and debugging the TMS320F28027FPTT?

A: Programming and debugging are typically handled via the standard JTAG interface, allowing in-depth development and troubleshooting using industry-standard tools. The integrated flash memory provides in-system programmability for firmware updates.

Q: How does the microcontroller ensure data reliability and system safety during operation?

A: System safety is enhanced through features like a built-in watchdog timer, brown-out reset, Class 2 (HBM) ESD protection, and reliable on-chip flash memory, minimizing faults caused by power glitches or harsh environmental conditions.
