Z3R-Q200P Red LED Pol Retro

Name: Z3R-Q200P Red LED Pol Retro
Brand: RKSEMITRONICS
Price: 5400 INR
Availability: InStock

Price 5400 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Z3R-Q200P Red LED Pol Retro Specification

Operating Temperature
-20C to +60C

Sensitivity
Adjustable

Interface
3-wire Connection

Mounting Type
Panel/Bracket Mount

Wireless
No

Power Consumption
<10 mA

Features
Polarized lens eliminates false detection, LED indicator

Measurement Range
0.1 m to 4 m

IP Rating
IP67

Cable Length
2 meter

Signal Type
Digital

Sensor Type
Polarized Retro-Reflective

Response Time
<10 ms

Application
Material Handling, Packaging, Presence Sensing

Product Type
Red LED Polarized Retro-reflective Sensor

Material
Polycarbonate Housing

Input
12-24V DC

Output
PNP/NPN

Function
Object Detection

Usage
Industrial Automation, Conveyor Systems

Accuracy
1%

Resolution
0.1 mm

Voltage
12-24 VDC

Weight
80g

Enclosure Color
Black/Red

Ambient Humidity
35% to 85% RH (Non-Condensing)

Reflector Type
Included, Standard Square Reflector

Light Source
High Brightness Red LED (660nm)

Housing Dimensions
M18 x 67mm

Status Indicators
LED Output status, Power-on Indicator

Connection Type
Pre-wired

Z3R-Q200P Red LED Pol Retro Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
10 Days

Main Domestic Market
All India

About Z3R-Q200P Red LED Pol Retro

SeriesZ3Sensor Body TypeCompact Rectangular PlasticSensor Body FeatureH31 x W11 x D20, brkt not includedSensing ModeRetro-reflectiveSensing Mode DetailsTransparent Detection, 2m distance using V-61 reflectorSensor Features1-turn potentiometer, beam spot 140mm, 0.5ms responseLight SourceRed LEDSupply Voltage Details10 to 30VDCSensing Range10mm to 2 meterOutputPNPOutput Details1 each PNPTimerNoOutput ModeLight-On/Dark-On selectableConstructionABS enclosure, PMMA lensTemperature-25 to +55 CIEC/Nema Rating DetailsIP67Connection DetailCable 2mItem Weight0.10 lbs per EA

High-Precision Detection for Industrial Applications

The Z3R-Q200P excels in fast, precise object detection across industrial environments, thanks to its 1% accuracy and 0.1 mm resolution. With a response time under 10 ms and adjustable sensitivity, it meets demanding automation requirements in packaging, presence sensing, and materials handling.

Durable Design, Simple Integration

Designed with a rugged polycarbonate housing, IP67 ingress protection, and a broad ambient temperature range, this sensor adapts well to harsh settings. Its panel or bracket mounting and pre-wired 2-meter cable ensure quick, secure installation for seamless factory integration.

Smart Features and Status Indicators

A polarized lens eliminates false detection from shiny surfaces, while LED indicators provide clear output and power status. The sensor operates at 12-24V DC and consumes minimal power, making it cost-effective for long-term industrial use.

FAQs of Z3R-Q200P Red LED Pol Retro:

Q: How is the Z3R-Q200P Red LED Polarized Retro-Reflective Sensor installed in industrial applications?

A: The sensor can be mounted using either a panel or bracket mount, and its pre-wired 2-meter cable with a 3-wire connection interface makes installation straightforward. Simply position the included reflector and align the sensor for optimal detection.

Q: What types of objects can the Z3R-Q200P reliably detect?

A: Thanks to its high-brightness 660nm red LED and polarized retro-reflective design, the sensor accurately detects a wide range of objects, including opaque and shiny materials, while avoiding false detections caused by background reflections.

Q: When should the sensors adjustable sensitivity be configured?

A: Adjust the sensitivity when installing the sensor to match the object size, background conditions, or desired detection range. Fine-tuning ensures optimal detection performance and eliminates unwanted triggers in your specific environment.

Q: Where is the Z3R-Q200P best utilized within an industrial setting?

A: It is ideal for use on conveyor systems, material handling lines, and packaging machinery where precise object presence, position, or passage must be monitored over distances from 0.1 m to 4 m.

Q: What process does the sensor follow for effective object detection?

A: The Z3R-Q200P emits a red LED beam towards a reflector. It detects objects that interrupt this beam, relaying digital signals (PNP/NPN) and activating LED status indicators for output and power events.

Q: How does the polarized lens benefit industrial detection tasks?

A: The polarized lens design significantly reduces false detection caused by glossy or reflective surfaces, resulting in more accurate readings and stable performance in challenging industrial lighting conditions.

Q: What are the main advantages of choosing the Z3R-Q200P for automation applications?

A: This sensor offers dependable operation in tough environments, fast and precise detection, low power consumption, clear status indication, and easy integration, making it an efficient and cost-effective choice for automation projects.
