CCG30-24-15S Isolated DC/DC Converters

Name: CCG30-24-15S Isolated DC/DC Converters
Brand: RKSEMITRONICS
Price: 4000 INR
Availability: InStock

Price 4000 INR/ Piece

Get a Price/Quote

MOQ : 2 Pieces

CCG30-24-15S Isolated DC/DC Converters Specification

Operating Temperature
-40C to +85C

Power Source
DC Input

Usage
Industrial Electronics

Features
High efficiency, Compact size, Over-current and Over-voltage protection, Short circuit protection, Remote ON/OFF control

Interface
PCB Mount

Power Supply
DC

Output
15V DC, 2A

Thermal Conductivity
Standard Air Cooling

Components
High Frequency Transformer, Regulator IC, MOSFET

IP Rating
IP20

Input
18-36V DC

Response Time
Fast Transient Response

Product Type
Power Module

Application
Industrial, Communication, Medical

Rated Voltage
24V DC

Supply Voltage
24V DC

Size
50.8mm x 25.4mm

Dimension (L*W*H)
50.8mm x 25.4mm x 10.2mm

Function
Isolated DC/DC Converter

Color
Black

Weight
40g

Thickness
10.2mm

Capacity
30W

Current Rating
2A

Frequency
Fixed Switching Frequency

Ripple & Noise
100mVp-p

Line Regulation
±0.2%

Mounting Type
Through Hole

Efficiency
Up to 91%

Cooling Method
Convection

Storage Temperature
-55°C to +125°C

Case Material
Metal

Isolation Voltage
1500V DC

Load Regulation
±0.5%

CCG30-24-15S Isolated DC/DC Converters Trade Information

Minimum Order Quantity
2 Pieces

Delivery Time
10 Days

Main Domestic Market
All India

About CCG30-24-15S Isolated DC/DC Converters

Manufacturer: TDK-Lambda Product Category: Isolated DC/DC Converters - Through Hole RoHS: Details REACH - SVHC: Mounting Style: Through Hole Number of Outputs: 1 Output Output Power: 30 W Input Voltage, Min: 9 V Input Voltage, Max: 36 V Output Voltage-Channel 1: 15 V Output Current-Channel 1: 2 A Output Voltage-Channel 2: - Output Current-Channel 2: - Isolation Voltage: 1.5 kV Minimum Operating Temperature: - 40 C Maximum Operating Temperature: + 85 C Package/Case: DIP-6 Length: 25.4 mm Width: 25.4 mm Height: 9.9 mm Industry: Industrial Product: Isolated Series: CCG30 Brand: TDK-Lambda Input Voltage: 9 V to 36 V Packaging: Tube Product Type: Isolated DC-DC Converters 1 Subcategory: DC-DC Converter Part # Aliases: CCG30-24-15S Unit Weight: 20 g

Advanced Isolation and Protection

Featuring a 1500V DC isolation barrier, the CCG30-24-15S ensures safety and integrity in power conversion systems, particularly in environments with sensitive electronics. The converter is fortified with over-voltage, over-current, and short-circuit protections, which help prevent equipment damage and support consistent system reliability.

Exceptional Performance and Efficiency

Engineered for efficiency and stability, this DC/DC converter operates at up to 91% efficiency, with excellent line regulation (0.2%) and load regulation (0.5%). These qualities make it ideal for industrial and medical environments where power quality is critical and energy saving is desired.

Compact and Versatile for Industrial Applications

With its low profile (only 10.2mm thick) and compact size (50.8mm x 25.4mm), the CCG30-24-15S integrates easily into circuit boards via through-hole mounting. It suits installations where space is limited and reliability is crucial, such as process automation, medical devices, and communication equipment.

FAQ's of CCG30-24-15S Isolated DC/DC Converters:

Q: How is the CCG30-24-15S DC/DC converter typically mounted onto a circuit board?

A: The CCG30-24-15S utilizes a through-hole mounting design, allowing it to be securely fixed onto standard PCB layouts. This approach provides mechanical stability and ease of integration into industrial or medical electronic systems.

Q: What protections does the converter provide for industrial applications?

A: It is equipped with comprehensive protections, including over-current, over-voltage, and short-circuit protection, ensuring safe operation and minimizing the risk of damage to connected components in demanding environments.

Q: When is the best application scenario for choosing this converter?

A: This converter is best used in settings where high reliability, electrical isolation, and efficiency are crucial, such as in industrial automation, communications infrastructure, and medical devices requiring regulated DC power.

Q: Where can users expect the most benefit from the high isolation voltage feature?

A: The isolation voltage of 1500V DC is especially beneficial in applications where operator safety and circuit separation are essential, such as medical instrumentation or systems with sensitive control electronics.

Q: What process does the converter use for heat dissipation?

A: The converter relies on convection cooling, allowing it to dissipate heat efficiently without the need for additional fans or heatsinks, supporting silent and maintenance-free operation.

Q: How does remote ON/OFF control functionality benefit users?

A: Remote ON/OFF capability enables users to manage power supply operations from a distance, allowing integration into automated control systems and enhancing operational safety and convenience.
